DC-DC Dönüştürücüler
| Fotoğraf | Üretici Parça # | Mevcutluk | Miktar | Veri Sayfası | Seri | Paket/Kutular | Paketlenme | Ürün Durumu | Tür | Çıkış Sayısı | Voltaj - Giriş (Minimum) | Voltaj - Giriş (Maksimum) | Voltaj - Çıkış 1 | Voltaj - Çıkış 2 | Voltaj - Çıkış 3 | Voltaj - Çıkış 4 | Akım - Çıkış (Maksimum) | Güç (Watt) | Voltaj - Yalıtım | Uygulamalar | Özellikler | Çalışma Sıcaklığı | Verimlilik | Sınıf | Kalite Belirtimi | Montaj Türü | Boyut / Ölçü | Tedarikçi Cihaz Paketi | Kontrol Özellikleri | Onay Ajansı | Standart Numarası |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LTM4686IV-1#PBFIC REG BCK ADJ 10A SGL/DL 108LGA |
28 |
|
Veri Sayfası |
µModule® | 108-LGA Module | Tray | Active | Non-Isolated PoL Module | 2 | 4.5V | 17V | 0.5 ~ 3.6V | 0.5 ~ 3.6V | - | - | 10A, 10A | - | - | ITE (Commercial) | Adjustable Output | -40°C ~ 125°C | - | - | - | Surface Mount | 0.63" L x 0.47" W x 0.07" H (16.0mm x 11.9mm x 1.82mm) | 108-LGA (16x11.9) | - | - | - |
|
TEN 40-2412WIEDC DC CONVERTER 12V 40W |
30 |
|
Veri Sayfası |
TEN 40WIE (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 3.333A | 40 W | 1.6 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 92% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | CB, cURus | - |
|
RP15-2405SFWDC DC CONVERTER 5V 15W |
46 |
|
Veri Sayfası |
POWERLINE RP15-FW (15W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 3A | 15 W | 1.6 kV | ITE (Commercial) | OCP, OVP, SCP | -40°C ~ 75°C | 86% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | - | - |
|
THN 30-4815WIR42 WATT DC/DC CONVERTER, RAILWAY |
39 |
|
Veri Sayfası |
THN 30WIR (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 1.25A | 30 W | 3 kV | ITE (Commercial), Railway | Adjustable Output, Remote On/Off | -40°C ~ 105°C | 92% | - | - | Through Hole | 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm) | - | - | CB, cURus | 62368-1 |
|
|
THN 30-4813WIR41 WATT DC/DC CONVERTER, RAILWAY |
32 |
|
Veri Sayfası |
THN 30WIR (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 75V | 15V | - | - | - | 2A | 30 W | 3 kV | ITE (Commercial), Railway | Adjustable Output, Remote On/Off | -40°C ~ 105°C | 91% | - | - | Through Hole | 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm) | - | - | CB, cURus | 62368-1 |
|
LTM4631IY#PBFDC DC CNVRTR 0.6-1.8V 0.6-1.8V |
81 |
|
Veri Sayfası |
µModule® | 144-BBGA | Tray | Active | Non-Isolated PoL Module | 2 | 4.5V | 15V | 0.6 ~ 1.8V | 0.6 ~ 1.8V | - | - | 10A | - | - | ITE (Commercial) | OCP, OVP, SCP, UVLO | -40°C ~ 125°C | - | - | - | Surface Mount | 0.63" L x 0.63" W x 0.11" H (16.0mm x 16.0mm x 2.7mm) | 144-BGA (16x16) | Enable, Active High | - | - |
|
JCK4024S05DC DC CONVERTER 5V 40W |
476 |
|
Veri Sayfası |
JCK (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 36V | 5V | - | - | - | 8A | 40 W | 1.6 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP, UVLO | -40°C ~ 100°C | 92% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | Enable, Active High | - | - |
|
LTM4641IY#PBFDC DC CONVERTER 0.6-6V |
87 |
|
Veri Sayfası |
µModule® | 144-BBGA Module | Tray | Active | Non-Isolated PoL Module | 1 | 4.5V | 38V | 0.6 ~ 6V | - | - | - | 10A | - | - | ITE (Commercial) | OCP, OTP, UVLO | -40°C ~ 125°C | - | - | - | Surface Mount | 0.59" L x 0.59" W x 0.20" H (15.0mm x 15.0mm x 5.0mm) | 144-BGA (15x15) | - | - | - |
|
PXD20-24S15DC DC CONVERTER 15V 20W |
50 |
|
Veri Sayfası |
PXD (20W) | 6-DIP Module | Bulk | Active | Isolated Module | 1 | 18V | 36V | 15V | - | - | - | 1.33A | 20 W | 1.6 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | - | 87% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | - | - |
|
20IMX4-1515-8GDC DC CONVERTER +/-15V 4W |
60 |
|
Veri Sayfası |
Melcher IMX4 (4W) | 24-DIP Module | Bulk | Active | Isolated Module, Conformal Coated | 2 | 8.4V | 36V | 15V | -15V | - | - | 140mA, 140mA | 4 W | 1.5 kV | ITE (Commercial), Railway | OCP, OTP, OVP, SCP | -40°C ~ 85°C | 82% | - | - | Through Hole | 1.30" L x 0.79" W x 0.34" H (33.0mm x 20.1mm x 8.6mm) | - | - | - | - |
|
PRC40-24-S5DC-DC, ISOLATED, 40 W, 9 ~ 36 VD |
35 |
|
Veri Sayfası |
PRC40 (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 8A | 40 W | 1.6 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) | - | - | CE, UKCA | 62368-1 |
|
LTM8050MPY#PBFDC DC CONVERTER 0.8-24V 48W |
32 |
|
Veri Sayfası |
µModule® | 70-BBGA Module | Tray | Active | Non-Isolated PoL Module | 1 | 3.6V | 58V | 0.8 ~ 24V | - | - | - | 2A | - | - | ITE (Commercial) | OTP | -55°C ~ 125°C | - | - | - | Surface Mount | 0.59" L x 0.35" W x 0.19" H (15.0mm x 9.0mm x 4.9mm) | 70-BGA (15x9) | - | - | - |
|
I7A4W033A033V-000-RDC DC CONVERTER 3.3-24V 500W |
44 |
|
Veri Sayfası |
i7A (750W) | Sixteenth Brick | Tray | Active | Non-Isolated PoL Module | 1 | 18V | 60V | 3.3V ~ 24V | - | - | - | 33A | 500 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 125°C | 97% | - | - | Through Hole | 1.45" L x 1.34" W x 0.45" H (36.8mm x 34.0mm x 11.5mm) | Sixteenth Brick | Enable, Active High | CE, cURus, IEC | 62368-1 |
|
AVD200-48S12B-6L12V 200W SIXTEENTH BRICK |
95 |
|
Veri Sayfası |
AVD200-48S12 (200W) | Sixteenth Brick | Tray | Active | Isolated Module | 1 | 36V | 75V | 12V | - | - | - | 17A | 204 W | 2.25 kV | ITE (Commercial) | Baseplate, Remote On/Off | -40°C ~ 85°C | 93.9% | - | - | Through Hole | 1.30" L x 0.90" W x 0.50" H (33.0mm x 22.9mm x 12.7mm) | Sixteenth Brick | - | CE, CSA, TUV, UL | 62368-1 |
|
THM 20-1223DC DC CONVERTER +/-15V 20W |
38 |
|
Veri Sayfası |
THM 20 (20W) | 5-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 18V | 15V | -15V | - | - | 667mA, 667mA | 20 W | 5 kV | Medical | OCP, OTP, OVP, SCP | -40°C ~ 80°C (With Derating) | 89% | - | - | Through Hole | 1.60" L x 1.00" W x 0.40" H (40.6mm x 25.4mm x 10.2mm) | - | - | - | - |
|
|
TEN 40-2411WIEDC DC CONVERTER 5V 40W |
77 |
|
Veri Sayfası |
TEN 40WIE (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 8A | 40 W | 1.6 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 92% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | CB, cURus | - |
|
LTM4662IYDC DC CNVRTR 0.6-5.5V 0.6-5.5V |
109 |
|
Veri Sayfası |
LTM®, uModule® | 88-BBGA Module | Tray | Active | Non-Isolated PoL Module | 2 | 4.5V | 20V | 0.6 ~ 5.5V | 0.6 ~ 5.5V | - | - | 15A, 15A | - | - | ITE (Commercial) | OCP, OVP, SCP, UVLO | -40°C ~ 125°C | 96% | - | - | Surface Mount | 0.59" L x 0.44" W x 0.25" H (15.0mm x 11.3mm x 6.3mm) | 88-BGA (15x11.25) | - | - | - |
|
TEN 20-2423DC DC CONVERTER +/-15V 20W |
27 |
|
Veri Sayfası |
TEN 20 (20W) | 6-DIP Module | Tube | Not For New Designs | Isolated Module | 2 | 18V | 36V | 15V | -15V | - | - | 670mA, 670mA | 20 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 85°C (With Derating) | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | - | - |
|
|
RP15-2415DFWDC DC CONVERTER +/-15V 15W |
50 |
|
Veri Sayfası |
POWERLINE RP15-FW (15W) | 6-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 36V | 15V | -15V | - | - | 500mA, 500mA | 15 W | 1.6 kV | ITE (Commercial) | OCP, OVP, SCP | -40°C ~ 75°C | 86% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | - | - |
|
|
RGC4W300W012A-003DC DC CONVERTER 9.6-48V 300W |
35 |
|
Veri Sayfası |
RGC (300W) | 34-DIP Module, 7 Leads | Tray | Active | Non-Isolated PoL Module | 1 | 9V | 53V | 5 ~ 28V | - | - | - | 12.5A | 350 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 115°C | 96% | - | - | Through Hole | 1.50" L x 1.95" W x 0.53" H (38.1mm x 49.5mm x 13.5mm) | - | Enable, Active Low | CE, UKCA | - |
