DC-DC Dönüştürücüler
| Fotoğraf | Üretici Parça # | Mevcutluk | Miktar | Veri Sayfası | Seri | Paket/Kutular | Paketlenme | Ürün Durumu | Tür | Çıkış Sayısı | Voltaj - Giriş (Minimum) | Voltaj - Giriş (Maksimum) | Voltaj - Çıkış 1 | Voltaj - Çıkış 2 | Voltaj - Çıkış 3 | Voltaj - Çıkış 4 | Akım - Çıkış (Maksimum) | Güç (Watt) | Voltaj - Yalıtım | Uygulamalar | Özellikler | Çalışma Sıcaklığı | Verimlilik | Sınıf | Kalite Belirtimi | Montaj Türü | Boyut / Ölçü | Tedarikçi Cihaz Paketi | Kontrol Özellikleri | Onay Ajansı | Standart Numarası |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PESE1-S24-S12-M-TRDC-DC ISOLATED 3KV, 1 W, 21.6~26 |
0 |
|
Veri Sayfası |
PESE1-M (1W) | 8-SMD Module, 5 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 1 | 21.6V | 26.4V | 12V | - | - | - | 84mA | 1.008 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | 0.52" L x 0.33" W x 0.29" H (13.2mm x 8.5mm x 7.3mm) | - | - | CE, cURus | 62368-1 |
|
1D14C_0515S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 81% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
1D14C_1212S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 12V | - | - | - | 83mA | 996 mW | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 80% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
1D14C_1205S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 80% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
1D14C_0505S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 80% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
1D14C_0503S3UPDC-DC INDUSTRIAL |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 3.3V | - | - | - | 303mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 75% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
1D14C_0512S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 12V | - | - | - | 83mA | 996 mW | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 80% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
1D14C_1215S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1D14C_S3UP&1D14C_D3UP (1W) | 14-DIP Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 81% | - | - | Through Hole | 0.79" L x 0.39" W x 0.28" H (20.0mm x 10.0mm x 7.0mm) | - | - | CE, cURus | 60950-1 |
|
|
AM2M-2405DH30JZ2W DC/DC Converter |
6 |
|
Veri Sayfası |
* | 14-DIP Module | Tube | Obsolete | Isolated Module | 2 | 21.6V | 26.4V | -5 ~ 5V | -5V | - | - | 200mA, 200mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Through Hole | 0.80" L x 0.40" W x 0.32" H (20.3mm x 10.2mm x 8.2mm) | - | - | - | 62368-1 |
|
|
AM2DS-2412DH30JZ2W DC/DC Converter |
4 |
|
Veri Sayfası |
* | 7-SIP Module | Tube | Obsolete | Isolated Module | 2 | 21.6V | 26.4V | -12 ~ 12V | -12V | - | - | 83mA, 83mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Through Hole | 0.77" L x 0.28" W x 0.40" H (19.7mm x 7.1mm x 10.2mm) | - | - | cURus | 62368-1 |
|
|
AM2DS-2415DH30JZ2W DC/DC Converter |
4 |
|
Veri Sayfası |
* | 7-SIP Module | Tube | Obsolete | Isolated Module | 2 | 21.6V | 26.4V | -15 ~ 15V | -15V | - | - | 67mA, 67mA | 2 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Through Hole | 0.77" L x 0.28" W x 0.40" H (19.7mm x 7.1mm x 10.2mm) | - | - | cURus | 62368-1 |
|
PDSE1-S5-D12-M-TRDC DC CONVERTER +/-12V 1W |
0 |
|
Veri Sayfası |
PDSE1-M (1W) | 10-SMD Module, 6 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 2 | 4.5V | 5.5V | 12V | -12V | - | - | 42mA, 42mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm) | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 62368-1 |
|
|
PDSE1-S5-D15-M-TRDC DC CONVERTER +/-15V 1W |
0 |
|
Veri Sayfası |
PDSE1-M (1W) | 10-SMD Module, 6 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 2 | 4.5V | 5.5V | 15V | -15V | - | - | 34mA, 34mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm) | - | - | CB Scheme, EN, IEC, UL | 55024; 55032 Class A; 62368-1 |
|
|
LMW78_6.5-0.5RDC-DC STEP DOWN REGULATORS |
0 |
|
Veri Sayfası |
LMW78_0.5R | 3-SIP Module | Tube | Active | Non-Isolated PoL Module | 1 | 9V | 90V | 6.5V | - | - | - | 500mA | 3.25 W | - | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | 0.45" L x 0.35" W x 0.69" H (11.5mm x 9.0mm x 17.5mm) | - | - | - | - |
|
PDS1-S12-S3-SDC DC CONVERTER 3.3V 1W |
0 |
|
Veri Sayfası |
PDS1-S (1W) | 4-SIP Module | Tube | Obsolete | Isolated Module | 1 | 10.8V | 13.2V | 3.3V | - | - | - | 303mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 76% | - | - | Through Hole | 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm) | - | - | - | - |
|
|
PDSE1-S24-D12-MDC-DC ISOLATED 1.5KV, 1 W, 21.6~ |
17 |
|
Veri Sayfası |
PDSE1-M (1W) | 10-SMD Module, 6 Leads | Tube | Not For New Designs | Isolated Module | 2 | 21.6V | 26.4V | 12V | -12V | - | - | 42mA, 42mA | 1.008 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 83% | - | - | Surface Mount | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm) | - | - | CE, cURus | 62368-1 |
|
|
PDSE1-S24-D5-M-TRDC-DC ISOLATED 1.5KV, 1 W, 21.6~ |
0 |
|
Veri Sayfası |
PDSE1-M (1W) | 10-SMD Module, 6 Leads | Tape & Reel (TR) | Not For New Designs | Isolated Module | 2 | 21.6V | 26.4V | 5V | -5V | - | - | 100mA, 100mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 82% | - | - | Surface Mount | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm) | - | - | CE, cURus | 62368-1 |
|
AM1LS-0503DH30VZDC DC CONVERTER +/-3.3V 1W |
5 |
|
Veri Sayfası |
AM1LS-VZ (1W) | SMD | Tube | Obsolete | Isolated Module | 2 | 4.5V | 5.5V | -3.3 ~ 3.3V | -3.3V | - | - | 151mA, 151mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 74% | - | - | Surface Mount | 0.60" L x 0.44" W x 0.28" H (15.2mm x 11.4mm x 7.3mm) | - | - | - | - |
|
1T8A1_0505S3UPISOLATED MODULE DC DC CONVERTERS |
0 |
|
Veri Sayfası |
1T8A1_3UP (1W) | 8-SMD Module, 5 Leads | Tube | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 5V | - | - | - | 200mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 82% | - | - | Surface Mount | 0.52" L x 0.33" W x 0.29" H (13.2mm x 8.5mm x 7.3mm) | - | - | CE, cURus | 62368-1 |
|
|
SPDC400FC12M0.35DC DC CONVERTER -12V |
0 |
|
Veri Sayfası |
SPDC400-4W | Module | Bulk | Obsolete | Non-Isolated PoL Module | 1 | 100V | 370V | -12V | - | - | - | 350mA | - | - | ITE (Commercial) | - | -10°C ~ 85°C | 80% | - | - | Surface Mount | 1.77" L x 0.94" W x 0.67" H (45.0mm x 24.0mm x 17.1mm) | - | - | - | - |
